Open top standard hook-lift containers
Heavy version container is a type of steel container, which is characterized by greater strength and load capacity than standard containers.
Heavy version containers are made of thicker steel sheet and have reinforced profiles and edges, which allows for safe storage and transport of heavy and voluminous goods, such as metals, machines, tools, building materials and others.
Heavy-duty containers are used in the transport and logistics industry as well as in warehouses and construction sites. Thanks to their strength and load capacity, they are an ideal solution for companies that need a safe and efficient way to store and transport heavy and large goods.
Heavy-duty containers are available in various sizes and configurations, allowing you to choose the right solution for your specific needs and requirements.
Technical data
- standard capacity 5-40 m3
- dimensions: inside width 2350 mm (2150 mm for municipal containers),length 4000-7000 mm, height 500-2400 mm
- sheet thickness: floor panel 5 mm, sidewall and front panels 3 mm 2 x 45° bent sheet floor jointed vertically, 90° angle on customer request
- IPE 180 / UNP 220 / UNP 140 I-beam frame, depending on container model
- reinforcing frames made of cold formed 80*50*4 C-beam, with 750 mm reinforcing frames span
- rear frame made of hot rolled UNP 160 C-beam
- double door with eccentric closure and central lock, welded hinges with a pin diameter of 30 mm
- Ø 159 mm container rollers, 300 mm wide, with a brass sleeve, axis diameter 40 mm (Ø 130 mm, 180 mm wide, axis diameter 30 mm for municipal containers)
- Ø 88,9 x 5 mm topping tube
- net/tarpaulin hooks
- inspection steps on the front panel
- all moving components equipped with grease nipples with covers
- lock handles equipped with ergonomic rubber caps
- container joints made continuously
- container components made of S235 and S355 steel (hook, hinge pins, roller axles)
- floor panel and sidewall panels can be made of DOMEX/HARDOX increased strength steel.
Additionally, containers can be equipped with:
- flap mounted on a transverse beam
- flap mounted on a transverse beam with rubber seal and screw clamps
- flap ramp with spring-loaded relief option (in containers up to 1.5 m high)
- flap-door (flap with integrated double door)
- hydraulically-lifted flap
- tarpaulin with a rubber band
- tarpaulin rolled on a tube with a crank
- straight or arch tarpaulin cross-straps
- load fixing points recessed into the floor panel or located in sidewall or front panels
- grain cover with adjustable slot
- other equipment, on individual order
